DIN Rail Three Phase Prepaid Energy Meter

CJ Electric ,one of leading producer of lower voltage products such as Energy Meter, Current Transformer, Frequency Inverter, Soft Starter, Power Meter, We specializes in research, design and manufacturing with an emphasis on continuous improvement, innovation and high performance and cost-effective solutions CJ Electric has developed as a global manufacturer.

Send Inquiry

Product Description

Applications, Features and Sphere of Application

Main features: Application of computer management, power utilization after purchasing power; limitation of maximal service power within the rated current range (prescribed by power supply department); one card only for one watt-hour meter, no electricity interruption even with the loss of the card and ensuring the power continuation after the re-registration; bilateral transmission of data and automatic power- cutting off to warn users to purchase power ; automatic switch-off operation when the electric quantity hits zero ; certain software design of anti-electricity-theft and so on .

Installed in the watt-hour meter boxes indoors or outdoors,DIN rail three phase prepaid energy meter apply to active power meter of frequency of 50HZ or 60HZ. Its ambient temperature ranges from -10℃ to 50℃ and its relative humidity is no more than 85%. It should stay away from the influence of corrosive gas, dust, salt mist and condensation.

Specification and Main Technical Parameters

1.Specification

Type	Accuracy	Basic current	Display Mode	Interface Mode
DDSY3666	1，2	5（20）A	LED LCD	Pulse
	1，2	10（40）A
	1，2	15（60）A

2. Intrinsic error

Load Current	Power Factor	Intrinsic Error（%）
Load Current	Power Factor	Class 1	Class 2
0.05Ib	1.0	±1.5	±2.5
0.1Ib-Imax	1.0	±1.0	±2.0
0.1Ib	0.5L 0.8C	±1.5	±2.5
0.2Ib-Imax	0.5L 0.8C	±1.0	±2.0

3.Starting current:

Under the conditions of the rated voltage, rated frequency and power, meter class I starts at 0.004Ib, meter class II starts at 0.005 Ib.

4.Watt-hour meter running without load:

When the line circuit of the watt-hour meter does not have current, and the line circuit has 115% rated power, the output pulse will not be more than one.

5.Power dissipation≦2W、10VA

6.Configuration and Dimension
